SPRINT 42 linear by DMG MORI

SPRINT 42 linear

High speed automatic turning with linear drives for the highest precision

Max. turning diameter
42 mm
Max. work piece length
120 mm
Max. bar capacity diameter
42 mm
Max. number of axes
8
Integrated motor spindle (ISM) with a C-axis (0,001°)
6,500 rpm
Max. number of tool pockets
26
Control & software alternatives
FANUC
Highlights
SPRINT 42 linear by DMG MORI

Automatic turning with 6 linear axes and 2 C-axes

  • Main spindle  with 6,500 rpm, 37,5 Nm, 5.5 kW
  • Counter spindle with 6,500 rpm, 19.6 Nm, 3.7 kW

Total of 26 tool stations

  • Up to 11 driven tools, 8 driven tool stations as standard, 3 driven frontal station
  • Driven tools spindles 5000 rpm, 3 Nm, 1.9 kW
  • Linear drive in X1 with 1 g acceleration for fastest dynamic and accuracy

DMG SLIMline featuring a 15" screen with FANUC 310i

  • 2 control channels, 6 linear axes and 2 C-axes
  • Tool Monitoring System with graphical tool load display as option
  • Up to 2 tools working simultaneously
SPRINT 42 linear by DMG MORI

Highest rigidity and accuracy

  • Constant stiffness due to large ball guide ways with balanced distance
  • Vertical covers and free chip fall
  • Integrated spindle motors for main and counter spindle with direct measuring systems
  • Thermo-symmetric machine bed  design for highest accuracy
Application Examples
Automation

Standard automation and customised solutions in the VERTICO design

Automation is a key element of digital production. Every DMG MORI machine can be upgraded with standard automation or with a customised automation solution for flexible manufacturing systems:

Control & Software
Service & Training
Technical Data & Downloads
Work Area
Max. turning diameter
42 mm
Max. work piece length
120 mm
Max. bar capacity diameter
42 mm
Axes
Max. number of axes
8
Max. number of linear axes
6
Max. number of Y-axes
2
Max number of C-axes
2
Main spindle
Integrated motor spindle (ISM) with a C-axis (0,001°)
6,500 rpm
Drive power rating (100% DC)
5.5 kW (AC)
Torque (100% DC)
37.5 Nm
Counter Spindle
Counter spindle available
Integrated motor spindle (ISM) with a C-axis (0,001°)
6,500 rpm
Drive power rating (100% DC)
3.7 kW (AC)
Torque (100% DC)
19.6 Nm
Tool carrier
Max. number of tool carriers
3
Max. number of tool pockets
26
Driven Tools / Max. tool speed
8 / 6500 rpm
Drive power rating (100% DC)
3.7 kW (AC)
Torque (100% DC)
19.6 Nm
Machine Size
Machine weight
5,500 kg
Floor Space incl chip conveyor, w/o inner coolant unit
8.9 sqm
